Thursday, December 16, 2010

Chimneys of TNB Paka Power Station

   These 16 chimneys of about 35 to 40m high are from 4 blocks of CCGT,
3 blocks are running on 6X95MW Alsthom GE Fr9 Gas Turbine with 3X 102MW Toshiba Steam Turbine and another one on 2X 90 MW  ABB 13D Gas Turbine with an Ansaldo 100MW Steam Turbine
giving an installed capacity of 1156MW.


The Alsthom GE Fr9 CCGT block.

This is the CCGT running on 2  Alstom ABB 13D Gas Turbine




Wednesday, November 24, 2010

Chimneys of YTL Paka Power Station

These 8 chimneys of YTL Paka Power Station are about 40m high
from 2 blocks of CCGT each with 2 Siemens 137mw V94.2 gas turbine
and a 130mw steam turbine generator giving a total output of 808mw.
For a record this is the first Independent Power Producer(IPP)
in Malaysia.











View YTL Paka Power Station in a larger map

YTL Power Services

Wednesday, October 27, 2010

Chimney ruins of an abandoned slope brick kiln

The ruins of this abandoned slope brick kiln
at Kuala Lukut with a 2 meter high leftover chimney
probably from one as high as 7meters.







It is dangerous to get into one of these kiln as it is in the verge of collapsing.












These holes though which heat is transfered up the slope to the next kiln
and it all ends at the chimney where the smoke makes an exit.























View Kuala Lukut abandoned slope brick kiln in a larger map

Friday, October 15, 2010

Labuan Chimney revisit

Labuan Chimney is one chimney which facinates me most,
it's mystery and actual purpose it was build for was so intriguing
that it caused me to start this chimney blog.
It had been 2 long years since my last visit to this beautiful chimney,
visits numbering more than a dozen time
since i first set foot on the this beautiful island in 1992
and being right under it again make me feel so contented and telling myself,
yes, i am back again trying to solve the mystery.
Earlier Post on Labuan Chimney





The Chimney Museum have a nice display of exibits from the coal mining era,
it will be very complete if a mine's train is still around.




The chimney viewed from Lubuk Temiang beach.
















The statement on the plaque about 'the inner wall of the chimney showed no sign of burning'
needs a change as there are clear sign of burned and overheated bricks
at the lowest 2 meter.



These over heated stains on the bricks clearly shows heat is moving up the chimney
from the two opening most probably from two brick kiln ,
one from each opening,kiln that could have been used to make bricks(for used in tunneling the mines)
or pottery(including chinese ceramics)
as there are plenty or clay and kaolin in the area
coupled with abundance of coal as a source of heat.
The pottery at Batu Arang,Selangor under similar conditions(underground coal mine)






This brick structure is probably a wall of a kiln.



Ceramic pottery littering the area behind the chimney towards Kubung Bluff
is a signs of early activitiy at Tanjung Kubung.


These are found by the seashore along Lubuk Temiang beach.






Thursday, September 30, 2010

Chimneys of PD Power

The 4 chimneys of Port Dickson Power which are about 40m high
are from 4 X 110MW GE9E open cycle Gas Turbine
giving a total output of 440MW.
This power plant looks more like a plant in a wetlands
as it is surrounded by a thick buffer of trees and natural lakes
to absorb sound emmitted from reaching the nearby housing.
The mangrove swamp inside and outside the plant attracts lot of wetland birds
like Kingfishers and Brahminy Kite.













A Brahminy Kite in flight.






Port Dickson Power
